ModelROF11-1*9WROF11-2*9WROF11-1*18WROF11-2*18WPower1*9W2*9W1*18W2*18WVoltageAC220VEx markExd llBT4/T6 GbEx tD A21 IP66T130℃/T80℃(Ex db lBT4/T6 Gb;Ex tb llIC T130℃IT80℃ Db)Cable sizeΦ6-10mmCable entryG1/2‘’Ip rati···
| Model | ROF11-1*9W | ROF11-2*9W | ROF11-1*18W | ROF11-2*18W |
| Power | 1*9W | 2*9W | 1*18W | 2*18W |
| Voltage | AC220V | |||
| Ex mark | Exd llBT4/T6 GbEx tD A21 IP66T130℃/T80℃ (Ex db lBT4/T6 Gb;Ex tb llIC T130℃IT80℃ Db) | |||
| Cable size | Φ6-10mm | |||
| Cable entry | G1/2‘’ | |||
| Ip rating | IP66 | |||
| Corrosion-proof grade | WF2 | |||
| Size and Application | ||||
| Model | ROF11-1*9W | ROF11-2*9W | ROF11-1*18W | ROF11-2*18W |
| Power | 1*9W | 2*9W | 1*18W | 2*18W |
| Product size(mm) | 706*626 | 706*626 | 1316*1236 | 1316*1236 |
| Packing size(mm) | 1400*190*130 | 1400*190*130 | 1380x190x160 | 1380x190x160 |
| Gross weight | / | / | 5.25 | 5.25 |
| Installation method | Ceiling mounted, pipe suspended, flange mounted, bent rod, guardrail mounted | |||
| Application | Explosive hazardous atmosphere Zone1, 2, &21, 22. | |||
| Model | ROF11-1*9W | ROF11-2*9W | ROF11-1*18W | ROF11-2*18W |
| Power | 1*9W | 2*9W | 1*18W | 2*18W |
| Voltage | AC220V | |||
| Ex mark | Exd llBT4/T6 GbEx tD A21 IP66T130℃/T80℃ (Ex db lBT4/T6 Gb;Ex tb llIC T130℃IT80℃ Db) | |||
| Cable size | Φ6-10mm | |||
| Cable entry | G1/2‘’ | |||
| Ip rating | IP66 | |||
| Corrosion-proof grade | WF2 | |||
| Size and Application | ||||
| Model | ROF11-1*9W | ROF11-2*9W | ROF11-1*18W | ROF11-2*18W |
| Power | 1*9W | 2*9W | 1*18W | 2*18W |
| Product size(mm) | 706*626 | 706*626 | 1316*1236 | 1316*1236 |
| Packing size(mm) | 1400*190*130 | 1400*190*130 | 1380x190x160 | 1380x190x160 |
| Gross weight | / | / | 5.25 | 5.25 |
| Installation method | Ceiling mounted, pipe suspended, flange mounted, bent rod, guardrail mounted | |||
| Application | Explosive hazardous atmosphere Zone1, 2, &21, 22. | |||
