Using LUMILEDS light source, high brightness, low light decay, long lifespan;Brand driven, with characteristics such as over temperature protection, high conversion rate, high power factor, and high lightning protection;···
Using LUMILEDS light source, high brightness, low light decay, long lifespan;
Brand driven, with characteristics such as over temperature protection, high conversion rate, high power factor, and high lightning protection;
ADC12 is die cast and has high thermal conductivity, allowing heat to be quickly dissipated from the body and balancing the temperature inside and outside the lamp body,
Reduce temperature difference, lower junction temperature of light source, and minimize light attenuation of light source;
The protection level can reach IP66, completely preventing dust from entering and high-pressure water spraying, suitable for moisture, dust or corrosiveness
Environment (such as ports, mines, chemical plants);
photoelectric parameters | ||||
Model | ROF12 | ROF12 | ROF12 | ROF12 |
Power | 50W | 70W | 100W | 150W |
Lumen | 5000LM | 7000LM | 1000LM | 15000LM |
Input voltage | AC100-277V | |||
Light efficiency | 100LM/W | |||
LED driver | NATE | |||
Lumileds | LUMILEDS | |||
CCT | 6000K(selectable3000-6500K) | |||
CRI | Ra≥70 | |||
PF | ≥0.9 | |||
Body material | Aluminum shell material | |||
Working Temp. | ’-25℃~+50℃ | |||
Warranty | 3 YEARS | |||
Size and Application | ||||
Model | ROF12 | ROF12 | ROF12 | ROF12 |
Power | 50W | 70W | 100W | 150W |
Product size(mm) | 200*140 | 200*140 | 260*150 | 260*150 |
