Die casting heat sink is made of 1060 Aluminum material with 99.6% aluminumcontent, good thermal conductivity and corrosion resistance.A variety of lenses such as 60°,90 °or 120 "can be selected with high transmit···
Die casting heat sink is made of 1060 Aluminum material with 99.6% aluminumcontent, good thermal conductivity and corrosion resistance.
A variety of lenses such as 60°,90 °or 120 "can be selected with high transmittance;
.It supports radar microwave light sensor, which can effectively suppress theinterference of high-order harmonics and other radio waves, with high sensitivitystrong reliability, safety and convenience, intelligent and energy-saving
Support round power supply/ ceiling bracket / power box, with a wider selection range
| photoelectric parameters | ||||
| Model | ROCP691 | ROCP691 | ROCP691 | ROCP691 |
| Power | 100W | 150W | 200W | 240W |
| Lumen | 15000LM | 22500LM | 30000LM | 36000LM |
| Input voltage | AC100-265V | |||
| Light efficiency | 150LM/W | |||
| LED driver | MOSO | |||
| Lumileds | LUMILEDS | |||
| CCT | 6000K(selectable3000-6500K） | |||
| CRI | Ra≥70 | |||
| PF | ≥0.95 | |||
| Body material | Aluminum shell material | |||
| Working Temp. | ’-25℃~+50℃ | |||
| Life Span | 50000h | |||
| Size and Application | ||||
| Model | ROCP691 | ROCP691 | ROCP691 | ROCP691 |
| Power | 100W | 150W | 200W | 240W |
| Product size(mm) | 158*292*290 | 164*350*350 | 184*380*380 | 184*380*380 |
| Installation method | Brackets | |||
| Application | Oil extraction, refining, chemical industry, military industry | |||
