Food-Grade Facility Lighting SolutionsDesigned specifically for hygienic environments in food processing plants, pharmaceutical facilities, and beverage production areas, our food-grade industrial lighting systems meet t···
Food-Grade Facility Lighting Solutions
Designed specifically for hygienic environments in food processing plants, pharmaceutical facilities, and beverage production areas, our food-grade industrial lighting systems meet the highest industry standards for safety, cleanliness, and durability.
Key Features:**
1. **Hygienic Design**
- Smooth, crevice-free surfaces with stainless steel housings (304/316 grade)
- IP65/IP66 rated waterproof/dustproof construction
- Easy-clean coatings resistant to chemical sanitizers (NaOH, H2O2, etc.)
2. **Food Safety Compliance**
- NSF/3-A certified materials
- FDA-compliant non-toxic components
- Zero particle shedding design
3. **Advanced Performance**
- High CRI (>85) for accurate color rendering
- 5000K-6500K daylight spectrum options
- Flicker-free LED technology (0% stroboscopic effect)
4. **Durability**
- -40°C to +55°C operational range
- Corrosion-resistant against moisture/steam
- 100,000+ hour LED lifespan (L90/B10)
5. **Sanitation-Friendly**
- Sealed gasket protection (NBR/EPDM options)
- Tool-free disassembly for cleaning
- UV-resistant polycarbonate diffusers
photoelectric parameters | ||||
Model | ROG08-60 | ROG08-100 | ROG08-150 | ROG08-200 |
Power | 60W | 100W | 150W | 200W |
Lumen | 10200LM | 17000LM | 25500LM | 34000LM |
Input voltage | AC220-240V | |||
Light efficiency | 170LM/W | |||
LED driver | Isolation drive | |||
Lumileds | Sanan2835 | |||
CCT | 6000K(selectable3000-6500K) | |||
CRI | Ra≥70 | |||
PF | ≥0.9 | |||
Beam angle | 60/90/120 | |||
Body material | Aluminum shell | |||
IP Rating | IP65 | |||
Working Temp. | ’-25℃~+50℃ | |||
Life Span | 50000h | |||
Warranty | Four years | |||
Size and Application | ||||
Model | ROG08-60 | ROG08-100 | ROG08-150 | ROG08-200 |
Power | 60W | 100W | 150W | 200W |
Product size(mm) | 300*73 | 300*73 | 360*78 | 420*83 |
Net weight(kg) | / | / | / | / |
Packing size(mm) | 365*365*130 | 365*365*130 | 415*415*135 | 485*485*130 |
Gross weight | / | / | / | / |
Installation height(m) | 4-7 meters | 6-10meters | 9-12meters | Above 13 meters |
Installation Space(m) | 4-7 meters | 6-8meters | 7-10meters | 9-10meters |
Installation method | Suspending, Brackets | |||
Application | workshop, warehouse, exhibition hall and other indoor area |
*Certifications:**
- ISOcertificate
- EN 60598-1 industrial luminaire standard
-CE,EMC certificate
**Applications:**
- Meat/poultry processing lines
- Dairy production areas
- Brewery fermentation zones
- Cold storage facilities (-30°C rating available)
- Cleanrooms (Class 100-100,000)
Food gade warehouse light Drawing
