Indoor Lighting

Food grade Facility Lighting

Food-Grade Facility Lighting SolutionsDesigned specifically for hygienic environments in food processing plants, pharmaceutical facilities, and beverage production areas, our food-grade industrial lighting systems meet t···

Category:Indoor Lighting
Wechat/WhatsApp:+8618896522176
Time:2024-07-15 10:04:34

    Food-Grade Facility Lighting Solutions

    Designed specifically for hygienic environments in food processing plants, pharmaceutical facilities, and beverage production areas, our food-grade industrial lighting systems meet the highest industry standards for safety, cleanliness, and durability.


    Key Features:**

    1. **Hygienic Design**

    - Smooth, crevice-free surfaces with stainless steel housings (304/316 grade)

    - IP65/IP66 rated waterproof/dustproof construction

    - Easy-clean coatings resistant to chemical sanitizers (NaOH, H2O2, etc.)


    2. **Food Safety Compliance**

    - NSF/3-A certified materials

    - FDA-compliant non-toxic components

    - Zero particle shedding design


    3. **Advanced Performance**

    - High CRI (>85) for accurate color rendering

    - 5000K-6500K daylight spectrum options

    - Flicker-free LED technology (0% stroboscopic effect)


    4. **Durability**

    - -40°C to +55°C operational range

    - Corrosion-resistant against moisture/steam

    - 100,000+ hour LED lifespan (L90/B10)


    5. **Sanitation-Friendly**

    - Sealed gasket protection (NBR/EPDM options)

    - Tool-free disassembly for cleaning

    - UV-resistant polycarbonate diffusers


    photoelectric parameters
    ModelROG08-60ROG08-100ROG08-150ROG08-200
    Power60W100W150W200W
    Lumen10200LM17000LM25500LM 34000LM
    Input voltageAC220-240V
    Light efficiency170LM/W
    LED driverIsolation drive
    LumiledsSanan2835
    CCT6000K(selectable3000-6500K)
    CRIRa≥70
    PF≥0.9
    Beam angle60/90/120
    Body materialAluminum shell
    IP RatingIP65
    Working Temp.’-25℃~+50℃
    Life Span50000h
    WarrantyFour years
    Size and Application
    ModelROG08-60ROG08-100ROG08-150ROG08-200
    Power60W100W150W200W
    Product size(mm)300*73300*73360*78420*83
    Net weight(kg) ////
    Packing size(mm)365*365*130365*365*130415*415*135485*485*130
    Gross weight////
    Installation height(m)4-7 meters6-10meters9-12metersAbove 13 meters
    Installation Space(m)4-7 meters6-8meters7-10meters9-10meters
    Installation methodSuspending, Brackets
    Application workshop, warehouse, exhibition hall and other indoor area


    *Certifications:**

    - ISOcertificate

    - EN 60598-1 industrial luminaire standard

    -CE,EMC certificate


    **Applications:**

    - Meat/poultry processing lines

    - Dairy production areas

    - Brewery fermentation zones

    - Cold storage facilities (-30°C rating available)

    - Cleanrooms (Class 100-100,000)


    Food gade warehouse light Drawing
