Features♦ Use high quality LED and power supply, to ensure the product reliability and life expectancy;♦ Innovative thin modularization heat body, air convection design, optimization of air duct, omni-directional three···
♦ Use high quality LED and power supply, to ensure the product reliability and life expectancy;
♦ Innovative thin modularization heat body, air convection design, optimization of air duct, omni-directional three-dimensional heat dissipation, greatly improved thermal performance;
♦ Use baking powder technology, increased corrosion resistance, looks shiny and will not discolored. Suitable for harsh outdoor environments;
♦ Professional optical lens, multiple beam angles, can meet customers’ different requirements;
♦ Multiple-choices brand LEDs and power supplies;
♦ Light sensor/Microwave sensor+dimming are both available;
♦ Hanging chain mounting / bracket mounting , suitable for most application places;
♦ Waterproof IP65;
♦ 5 years warranty.
photoelectric parameters | ||||
Model | ROS01B-30 | ROS01B-50 | ROS01B-100 | ROS01B-120 |
Power | 30W | 50W | 100W | 120W |
Lumen | 3300LM | 5500LM | 11000LM | 13200LM |
Input voltage | AC100-277V | |||
Light efficiency | 110LM/W | |||
LED driver | Suncom | |||
Lumileds | Lumileds | |||
CCT | 6000K(selectable3000-6500K) | |||
CRI | Ra≥70 | |||
PF | ≥0.9 | |||
Beam angle | 120 | |||
Body material | Aluminum shell material | |||
IP Rating | IP65 | |||
Working Temp. | ’-25℃~+50℃ | |||
Life Span | 50000h | |||
Warranty | Three years | |||
Size and Application | ||||
Model | ROS01B-30 | ROS01B-50 | ROS01B-100 | ROS01B-120 |
Power | 30W | 50W | 100W | 120W |
Product size(mm) | 294*64*44 | 575*64*44 | 1002*64*44 | 1182*64*44 |
Installation method | Brackets | |||
Application | Tunnels, squares, sports stadiums, airports and other places |
