*Integrated forming forging process, precise plasticity, improve the mechanicalproperties and structural strength of lamps, large heat dissipation area andgood thermal conductivityIt adopts large area die casting innovat···
*Integrated forming forging process, precise plasticity, improve the mechanicalproperties and structural strength of lamps, large heat dissipation area andgood thermal conductivity
It adopts large area die casting innovative heat dissipation structure design,
*Innovative hollow design, new hollow holes make the hot air form left and rightconvection air duct, 3D three-dimensional heat dissipation, further enhance theheat dissipation effect
| photoelectric parameters | ||||
| Model | ROCP693 | ROCP693 | ROCP693 | ROCP693 |
| Power | 50W | 100W | 150W | 180W |
| Lumen | 5500LM | 11000LM | 16500LM | 19800LM |
| Input voltage | AC85-265V | |||
| Light efficiency | 110LM/W | |||
| CCT | 6000K(selectable3000-6500K） | |||
| CRI | Ra≥75 | |||
| PF | ≥0.95 | |||
| Body material | Aluminum shell material | |||
| Working Temp. | ’-25℃~+50℃ | |||
| Life Span | 50000h | |||
| Size and Application | ||||
| Model | ROCP693 | ROCP693 | ROCP693 | ROCP693 |
| Power | 50W | 100W | 150W | 180W |
| Product size(mm) | 170*333*333 | 170*333*333 | 190*383*383 | 210*433*433 |
| Installation method | Brackets | |||
| Application | Indoor places such as workshops, warehouses, factories, exhibition halls, etc | |||
